MATH 1401 · Dr. Barry Monk

Measures of Spread (Continued) and Measures of Position

Sections 3.2 & 3.3

Last time ended on the variance, measured in squared units. We start by taking its square root.

Section 3.2 · Objective 3 of 4

Compute the standard deviation of a population and a sample

Definition

Standard Deviation

Since variance is calculated using squared deviations, its units are the squared units of the data. However, it’s often more practical to use a measure of spread with the same units as the data. This is achieved by taking the square root of the variance, resulting in the standard deviation.

Population Standard Deviation σ=σ2
Sample Standard Deviation s=s2
Example

Example: San Francisco Temperatures

Recall: the population variance of these temperatures is σ2=14.083 degrees squared.

What is the standard deviation, in degrees?

JanFebMarAprMayJunJulAugSepOctNovDec
San Francisco515455565860606163625852
σ=14.083=3.753

σ = 3.753 degrees: back in the units of the data.

Calculator

The 1-Var Stats output, in the Statistics Calculator and on the TI-84 Plus, gives both the sample standard deviation and the population standard deviation.

Data:578101113

The Standard Deviation is Not Resistant

Like the mean, it is significantly affected by extreme values.

Mean 42.9 Standard deviation 24.9 Median 40.0
Drag any value. Watch which measure stays put.
Section 3.2 · Objective 4 of 4

Use The Empirical Rule to summarize data that are unimodal and approximately symmetric

The Empirical Rule

When a data set has a bell-shaped histogram, it is often possible to use the standard deviation to provide an approximate description of the data using a rule known as The Empirical Rule.

Approximately 68% of the data will be within one standard deviation of the mean.

μ−σ to μ+σ40 to 60

Approximately 95% of the data will be within two standard deviations of the mean.

μ−2σ to μ+2σ30 to 70

All, or almost all, of the data will be within three standard deviations of the mean.

μ−3σ to μ+3σ20 to 80
Example

Example: The Empirical Rule

Projections of the percentage of the population aged 65 and over are given for each state and the District of Columbia. Describe the population using the Empirical Rule.

14.114.314.417.812.014.912.613.712.813.813.712.413.8
14.113.314.316.08.111.514.110.212.413.415.612.813.9
12.314.115.313.013.610.512.413.513.910.711.514.312.7
13.112.212.415.012.613.613.715.514.69.012.214.0
Solution:

Check the condition first: is the histogram bell-shaped?

The histogram is bell-shaped, so the Empirical Rule applies.

Calculator

Example: The Empirical Rule

Enter the 51 values in the Statistics Calculator and choose Summarize.

The Statistics Calculator’s 1-Var Stats card for list L1, n = 51 values, cropped to its Center and Spread rows: mean x̄ 13.25, median 13.6, no mode, sample sd s 1.699 and population sd σ 1.683. The mean and population sd rows are each marked.

These 51 values are the whole population, so μ=13.25 and σ=1.683.

The calculator labels the mean x¯ and also prints s; for a population, we use μ and σ.

Example

Example: The Empirical Rule

We compute six quantities:

Recall: μ=13.25, σ=1.683

μ−σ=13.25−1.683=11.57 μ+σ=13.25+1.683=14.93

Approximately 68% of the data values are between 11.57 and 14.93.

μ−2σ=13.25−2(1.683)=9.88 μ+2σ=13.25+2(1.683)=16.62

Approximately 95% of the data values are between 9.88 and 16.62.

μ−3σ=13.25−3(1.683)=8.20 μ+3σ=13.25+3(1.683)=18.30

Almost all of the data values are between 8.20 and 18.30.

Check Your Understanding

Commute Times

Commute times in a city have a bell-shaped histogram, with mean μ=30 minutes and standard deviation σ=6 minutes.

1

About what percent of commute times are between 24 and 36 minutes?

About 68%. 24 and 36 are one standard deviation from the mean: 30−6=24 and 30+6=36. 2

About 95% of commute times are between what two values?

18 and 42 minutes. 30−2(6)=18 · 30+2(6)=42 3

All, or almost all, commute times are between what two values?

12 and 48 minutes. 30−3(6)=12 · 30+3(6)=48
Recap

Section 3.2: Measures of Spread

Standard Deviation

The square root of the variance, so it carries the same units as the data.

s=s2 σ=σ2
The Empirical Rule

For a bell-shaped data set, approximately 68% of the data lies within one standard deviation of the mean, approximately 95% within two, and all, or almost all, within three.

Measures of Position

Section 3.3
Section 3.3 · Objective 1 of 4

Compute and interpret z-scores

Definition

z-Score

Let x be a value from a population with mean μ and standard deviation σ. The z-score of x is:

z=x−μσ
Interpretation:

The z-score of an individual data value tells how many standard deviations that value is from its population mean.

For example, a value one standard deviation above the mean has a z-score of z=1 and a value two standard deviations below the mean has a z-score of z=−2.

A man and a woman standing outdoors in tall grass under a pale overcast sky. The man is nearer the camera on the left and the woman a little behind him on the right; he is noticeably the taller of the two.
Example

Example: Comparing Heights

A study shows the average height for U.S. men is 69.4 inches (σ=3.1) and for women is 63.8 inches (σ=2.8).

Who is taller relative to their gender: a 73-inch man or a 68-inch woman?

zMan’s Height=x−μσ=73−69.43.1=1.16 zWoman’s Height=x−μσ=68−63.82.8=1.50

The woman is taller, relative to the population of women’s heights.

Section 3.3 · Graphical interpretation

The Two Heights on One Scale

Adult men
μ=69.4
Adult women
μ=63.8
One shared scale
z

Finding a Value with a Given z-Score

To find a value from a given z-score, multiply the z-score by the standard deviation, then add the result to the mean.

x=μ+z·σ
Example:

Data from the National Health and Nutrition Examination Survey show that for U.S. adults, the mean cholesterol level is μ=200 mg/dL (σ=44). What is the cholesterol level for someone with a z-score of 1.5?

Solution:
x=μ+z·σ=200+1.5(44)=266

The cholesterol level is 266 mg/dL.

The Empirical Rule & z-Scores

The Empirical Rule, in z-scores

About 68% of the data have z-scores between −1 and 1.

About 95% have z-scores between −2 and 2.

All, or almost all, have z-scores between −3 and 3.

A long airport concourse in low evening light, windows down one side and gate signs overhead. Two travellers with wheeled luggage walk away from the camera in the middle distance.
Check Your Understanding

z-Scores at the Airport

The Wall Street Journal reports that the average maximum distance from check-in to the gate at top U.S. airports is μ=0.79 miles (σ=0.42 miles).

1

The maximum distance at the Seattle-Tacoma International Airport is 0.57 miles. What is the z-score for this distance?

z=0.57−0.790.42=−0.52 2

What distance would have a z-score of 1?

x=0.79+1(0.42)=1.21miles
Section 3.3 · Objective 2 of 4

Compute the quartiles of a data set

Quartiles

We’ve learned how to compute the mean and median of a data set as measures of the center. Sometimes, it is useful to compute measures of position other than the center.

Quartiles divide a data set into four approximately equal pieces.

Q1

The first quartile, Q1, separates the lowest 25% of the data from the highest 75%.

Q2

The second quartile, Q2, divides the data so that 50% is below and 50% is above, essentially representing the median.

Q3

The third quartile, Q3, separates the lowest 75% of the data from the highest 25%.

An American goldfinch perched on a thin branch, in profile.

Suppose…

The third quartile of the lifespan of a certain type of Goldfinch is approximately 72 months.

This means…
75%

That 75% of this type of Goldfinch do not live for more than 72 months.

25%

Or 25% of them live for more than 72 months.

Example

Example: Computing Quartiles

The table below shows the February annual rainfall in Los Angeles over several years (in inches). Calculate the quartiles.

0.000.030.080.160.170.200.290.560.700.790.830.921.221.301.48
1.641.721.902.372.843.063.123.213.293.543.573.583.714.134.17
4.274.374.644.894.945.545.596.106.617.968.878.9111.0212.7513.68
First quartileThird quartile

Q1=0.875 and Q3=4.915.

Visualizing the Quartiles

Percentiles

Percentiles divide a data set into hundredths.

p and (100−p)50 and 50

For any number p between 1 and 99, the pth percentile separates the lowest p50% of the data from the highest (100−p)50%.

Visualizing Percentiles

A smiling student in a classroom holding up a completed exam paper towards the camera, with classmates at desks behind her.
Check Your Understanding

The 10th Percentile

After getting her recent statistics exam score, Aminah boasted to her friends, “I scored in the 10th percentile of the class!”

Does Aminah have a reason to brag?

No. Scoring in the 10th percentile means 90% of the class scored above her.

Section 3.3 · Objective 3 of 4

Compute the five-number summary for a data set

Definition

Five-Number Summary

The five-number summary of a data set consists of the median, the first quartile, the third quartile, the smallest value, and the largest value. These values are generally arranged in order.

Minimum First Quartile Median Third Quartile Maximum
Calculator

Five-Number Summary with Technology

The five-number summary is often part of the output when using technology.

Section 3.3 · Objective 4 of 4

Understand the effects of outliers

Definition

Outliers

An outlier is a value significantly larger or smaller than most in a data set.

Some outliers arise from errors, like a misplaced decimal point, causing the value to stand out.

Other outliers are accurate and reflect the presence of extreme values in the population.

Definition

Interquartile Range

One method for detecting outliers involves a measure called the Interquartile Range (IQR). The interquartile range is found by subtracting the first quartile from the third quartile: IQR=Q3−Q1.

Any data value beyond the outlier boundaries may be an outlier.

Lower Outlier Boundary Q1−1.5(IQR)
Upper Outlier Boundary Q3+1.5(IQR)
Example

Example: Outliers

The table shows the number of students absent from school each day in January. Identify any outliers in the data.

6567715751494441594942
56457744424546100595351
Solution:

From the Statistics Calculator: Q1=45 and Q3=59.

IQR=Q3−Q1=59−45=14
Lower Boundary:Q1−1.5(IQR)=45−1.5(14)=24
Upper Boundary:Q3+1.5(IQR)=59+1.5(14)=80

The value 100 is an outlier because it is greater than 80.

The Statistics Calculator’s 1-Var Stats card for list L1, n = 22 values, cropped to the IQR row and the Position block: IQR 14, minimum 41, Q1 45, median 51, Q3 59, maximum 100. The IQR, Q1 and Q3 rows are each marked.
Recap

Section 3.3: Measures of Position

z-Scores

The z-score of an individual data value tells how many standard deviations that value is from its population mean.

z=x−μσ
Quartiles & Percentiles

Quartiles divide a data set into four approximately equal pieces; percentiles divide it into a hundred.

Q1Q2Q3
Five-Number Summary

The five-number summary of a data set consists of the median, the first quartile, the third quartile, the smallest value, and the largest value.

Outliers

One method for detecting outliers involves a measure called the Interquartile Range (IQR).

IQR=Q3−Q1

You Are Ready For:

3.2 HW: Measures of Spread

3.3 HW: Measures of Position
